4 cc/rev Hydraulic Gear Pump - CBHS-FL304 | Factory Direct & Customizable

Dung tích:4 cc/vòng

Áp suất định mức:Áp suất 20 MPa (2900 psi)

Áp suất tối đa:Áp suất 25 MPa (3625 psi)

Tốc độ tối đa:3000 vòng/phút

Chiều quay:R: Phải (cùng chiều kim đồng hồ)

Thương hiệu:BXHS

Loại sản phẩm:Bơm bánh răng thủy lực

Dòng sản phẩm:Dòng Máy Bơm Bánh Răng Thủy Lực CBHS-FL3 Bơm bánh răng thủy lực

Kích thước bao bì:20*30*20

Tổng trọng lượng:9.00 kg

Tình trạng hàng: Còn hàng

1721 Lượt xem tìm kiếm sản phẩm này

4 cc/rev Hydraulic Gear Pump - CBHS-FL304 | Factory Direct & Customizable

4 cc/rev Hydraulic Gear Pump - CBHS-FL304 | Factory Direct & Customizable

4 cc/rev Hydraulic Gear Pump - CBHS-FL304 | Factory Direct & Customizable drawing image

The CBHS-FL304 4 cc/rev Hydraulic Gear Pump is a high-performance, durable pump designed for use in a wide range of applications, including construction, agriculture, industrial vehicles, and material handling. It is available in various configurations and is customizable to meet specific requirements.

Dòng Máy Bơm Bánh Răng Thủy Lực CBHS-FL3 Bơm bánh răng thủy lực Tham số
Dung tích 10 cc/vòng, 4 cc/vòng, 20 cc/vòng, 16 cc/vòng, 14 cc/vòng, 6 cc/vòng
Áp suất định mức Áp suất 20 MPa (2900 psi)
Áp suất tối đa Áp suất 25 MPa (3625 psi)
Tốc độ định mức 2000 vòng/phút
Tốc độ tối đa 3000 vòng/phút
Chiều quay L: Trái (ngược chiều kim đồng hồ), R: Phải (cùng chiều kim đồng hồ)
Vật liệu Nhôm
Cấu trúc Bơm bánh răng ngoài
Phiên bản mặt bích A-Bích bầu dục
Loại trục H: Rãnh then hình chữ nhật, X: Rãnh then cong, P: Khóa trơn

This CBHS-FL304 4 cc/rev Hydraulic Gear Pump is a robust and reliable component for various machinery. It is a factory direct product, meaning you are getting it straight from the manufacturer, ensuring competitive pricing and direct communication. Furthermore, the pump is customizable, allowing you to tailor it to your specific needs and application. The pump boasts a displacement of 10 cc/rev and a rated pressure of 20 MPa (2900 psi), making it suitable for demanding applications. Its rated speed is 2000 r/min with a maximum speed of 3000 r/min. The pump is available in both left and right rotation options. Constructed with an internal gear pump design using high-quality aluminium, it is durable and built to withstand demanding environments. The pump comes with an A-Oval Flange and Plain Key shaft for easy integration and compatibility with various machinery. The CBHS-FL304 pump is designed to be utilized in a wide array of machinery, including telehandlers, forklifts, mini-excavators, skid steer loaders, compact wheel loaders, wheel loaders, backhoe loaders, tractors and front-end loaders, harvesters, and balers. This versatile pump ensures its suitability across different applications within the construction, agriculture, industrial vehicles, and material handling sectors.
