16 cc/rev Hydraulic Gear Pump: Factory Direct & Customizable

Dung tích:16 cc/vòng

Áp suất định mức:Áp suất 20 MPa (2900 psi)

Áp suất tối đa:Áp suất 25 MPa (3625 psi)

Tốc độ tối đa:3000 vòng/phút

Chiều quay:R: Phải (cùng chiều kim đồng hồ)

Thương hiệu:BXHS

Loại sản phẩm:Bơm bánh răng thủy lực

Dòng sản phẩm:Dòng Máy Bơm Bánh Răng Thủy Lực CBHS-FL3 Bơm bánh răng thủy lực

Kích thước bao bì:20*20*20

Tổng trọng lượng:7.00 kg

Tình trạng hàng: Còn hàng

1104 Lượt xem tìm kiếm sản phẩm này

16 cc/rev Hydraulic Gear Pump: Factory Direct & Customizable

16 cc/rev Hydraulic Gear Pump: Factory Direct & Customizable

16 cc/rev Hydraulic Gear Pump: Factory Direct & Customizable drawing image

This 16 cc/rev hydraulic gear pump is designed for high-performance applications in construction, agriculture, and material handling. It features a durable aluminum construction, high pressure rating, and customizable options to meet your specific needs. The pump is suitable for various equipment types, including forklifts, telehandlers, skid steer loaders, and more.

Dòng Máy Bơm Bánh Răng Thủy Lực CBHS-FL3 Bơm bánh răng thủy lực Tham số
Dung tích 10 cc/vòng, 4 cc/vòng, 20 cc/vòng, 16 cc/vòng, 14 cc/vòng, 6 cc/vòng
Áp suất định mức Áp suất 20 MPa (2900 psi)
Áp suất tối đa Áp suất 25 MPa (3625 psi)
Tốc độ định mức 2000 vòng/phút
Tốc độ tối đa 3000 vòng/phút
Chiều quay L: Trái (ngược chiều kim đồng hồ), R: Phải (cùng chiều kim đồng hồ)
Vật liệu Nhôm
Cấu trúc Bơm bánh răng ngoài
Phiên bản mặt bích A-Bích bầu dục
Loại trục H: Rãnh then hình chữ nhật, X: Rãnh then cong, P: Khóa trơn

This 16 cc/rev hydraulic gear pump is a heavy-duty, high-performance solution for various applications. It boasts a 20 MPa (2900 psi) rated pressure and a 2000 r/min rated speed, with a maximum speed of 3000 r/min. This pump features a robust internal gear design, constructed from aluminum for long-lasting durability. Its A-Oval flange and plain key shaft provide flexible mounting options. The CBHS-FL3 Series pump is specifically designed for use in material handling, construction and earth moving, agriculture, and industrial vehicles. This makes it a versatile option for a wide range of equipment types, including forklifts, telehandlers, skid steer loaders, compact wheel loaders, mini- and midi- excavators, tractors and front-end loaders, harvesters, balers, and sprayers.
